When you need a smart, dependable contractor or plumber, count on our team of independent professionals for your heating, cooling and water heating needs.
Commercial Tankless Innovation Commercial Tankless Innovation
Commercial Tankless Innovation Commercial Tankless Innovation

TOOLS, PRODUCTS & SUPPORT
TO MEET CLIENT NEEDS

Introducing Rheem® Commercial Condensing Tankless Water Heaters—the most popular brand of tankless water heaters1—and the best option for commercial projects and applications. This ever-expanding commercial tankless line now includes eight new units with four built-in manifold control ready options and common venting availability on all indoor models.

Commercial Ready

Rheem Commercial Tankless Water Heaters are made for hardworking environments, with high-temp chip factory-installed

System Redundancy

Select models allow up to 20 units to be daisy-chained together via the included manifold control cable

Rheem EZ Rack™ Kit

Compactly packaged, it can be assembled on site and configured for any installation scenario

Built-in Condensate Neutralizer

The built-in condensate neutralizer raises the pH of the water so it can be safely discharged into the drain, preventing corrosion and damage

com-tankless-img-9
com-tankless-img-27

com-tankless-img-10

Service Notification Setting

Proper service and maintenance can lead to a longer life for the water heater. This maintenance alert feature is set by the contractor upon installation at the owner’s request. After 500 hours of use, the owner is alerted via a flashing warning code that it is time to service the unit

EcoNet Upgradeable

Add an EcoNet® WiFi Kit for the ability to control and monitor single or manifolded water heaters from anywhere2. EcoNet also sends mobile reminders when it’s time for maintenance. And if it detects a water leak, it shuts off gas and water to prevent damage3.

Overheat Detection Override

In the event the system overheats, Rheem’s exclusive Overheat Film Wrap will immediately shut the unit down to prevent damage.

Exclusive Hot Start Programming

When the tap is turned off and the initial call for hot water is complete, a typical tankless unit will shut down immediately. Rheem Tankless Water Heaters remain in a ready-fire position for five minutes after use, reducing the cold water sandwich effect in back-to-back usage.

Hard Water Buildup Warning

Hard water that can lead to scale buildup is common in many parts of the country, and left untreated, can reduce the unit’s efficiency and ability to provide hot water. Our built-in service alert automatically displays in the event the water heater detects scale buildup.

Service Valves Included

Every Rheem Commercial Tankless unit includes service valves. With their installation on cold inlet and hot outlet pipes, it can be isolated into individual units. This way, it’s easy to identify the unit that requires flushing or other maintenance—all without shutting down the entire bank of tankless units.

Common Vent Compatible

Common vent up to eight units with the Rheem header kits, complete with non-return valves. Elbows and termination kits are also available. Venting multiple units together saves space and materials and reduces outside wall penetrations.

com-tankless-img-13

Rheem Tankless Advantages

Rheem offers the industry’s only complete Commercial Tankless Line that includes:

  • Manifold Control Ready Units
  • Hot Start Programming
  • Overheat Film Wrap

Commercial Tankless Systems

Rheem makes it easy to create a multi-unit manifold setup with the Rheem Commercial Tankless System. Available in wall-mounted, wall-hung and free-standing configurations, this pre-engineered system comes fully built and ready to go.

X
MODEL UNITS DESCRIPTION FUEL TYPE LAYOUT
RTR-WM220DVLN 2-Units Indoor Wall Mount Nat. Gas
RTR-WM220XLN 2-Units Outdoor Wall Mount Nat. Gas
RTR-WM220DVLP 2-Units Indoor Wall Mount LP Gas
RTR-WM220XLP 2-Units Outdoor Wall Mount LP Gas
RTR-WM330DVLN 3-Units Indoor Wall Mount Nat. Gas
RTR-WM330XLN 3-Units Outdoor Wall Mount Nat. Gas
RTR-WM330DVLP 3-Units Indoor Wall Mount LP Gas
RTR-WM330XLP 3-Units Outdoor Wall Mount LP Gas
X
MODEL UNITS DESCRIPTION FUEL TYPE LAYOUT
RTR-WH220DVLN 2-Units Indoor Wall Hanging Nat. Gas
RTR-WH220XLN 2-Units Outdoor Wall Hanging Nat. Gas
RTR-WH220DVLP 2-Units Indoor Wall Hanging LP Gas
RTR-WH220XLP 2-Units Outdoor Wall Hanging LP Gas
RTR-WH330DVLN 3-Units Indoor Wall Hanging Nat. Gas
RTR-WH330XLN 3-Units Outdoor Wall Hanging Nat. Gas
RTR-WH330DVLP 3-Units Indoor Wall Hanging LP Gas
RTR-WH330XLP 3-Units Outdoor Wall Hanging LP Gas
X
MODEL UNITS DESCRIPTION FUEL TYPE LAYOUT
RTR-FS411DVLN 2-Units Indoor Free Standing Nat. Gas
RTR-FS411XLN 2-Units Outdoor Free Standing Nat. Gas
RTR-FS411XVLP 2-Units Outdoor Free Standing LP Gas
RTR-FS420DVLN 2-Units Indoor Free Standing Nat. Gas
RTR-FS420XLN 2-Units Outdoor Free Standing Nat. Gas
RTR-FS420XLP 2-Units Outdoor Free Standing LP Gas
RTR-FS630DVLN 3-Units Indoor Free Standing Nat. Gas
RTR-FS630XLN 3-Units Outdoor Free Standing Nat. Gas
RTR-FS630XLP 3-Units Outdoor Free Standing LP Gas
RTR-FS412DVLN 3-Units Indoor Free Standing Nat. Gas
RTR-FS412XLN 3-Units Outdoor Free Standing Nat. Gas
RTR-FS412XLP 3-Units Outdoor Free Standing LP Gas
RTR-FS422DVLN 4-Units Indoor Free Standing Nat. Gas
RTR-FS422XLN 4-Units Outdoor Free Standing Nat. Gas
RTR-FS422XLP 4-Units Outdoor Free Standing LP Gas
RTR-FS623DVLN 5-Units Indoor Free Standing Nat. Gas
RTR-FS623XLN 5-Units Outdoor Free Standing Nat. Gas
RTR-FS623XLP 5-Units Outdoor Free Standing LP Gas
RTR-FS633DVLN 6-Units Indoor Free Standing Nat. Gas
RTR-FS633XLN 6-Units Outdoor Free Standing Nat. Gas
RTR-FS633XLP 6-Units Outdoor Free Standing LP Gas

Cross Reference Chart Commercial Tankless Models

Model Rheem® Rinnai® Noritz® Navien®
Commercial Tankless
199,900 BTU/h Indoor NG TGH-C95DVLN C199i (KBD3237FFUDC) NCC1991 NPE-240A / NPE-240S
199,900 BTU/h Outdoor NG TGH-C95DVLP C199e (KB3237WDC) NCC1991 NPE-240A / NPE-240S
199,900 BTU/h Indoor LP TGH-C95XLN C199i (KBD3237FFUDC) NCC1991 NPE-240A / NPE-240S
199,900 BTU/h Outdoor LP TGH-C95XLP C199e (KB3237WDC) NCC1991 NPE-240A / NPE-240S
Commercial Tankless with Manifold Controls
199,900 BTU/h Indoor NG TGH-C95DVLN Not Available Not Available NPE-240A / NPE-240S
199,900 BTU/h Outdoor NG TGH-C95DVLP Not Available Not Available NPE-240A / NPE-240S
199,900 BTU/h Indoor LP TGH-C95XLN Not Available Not Available NPE-240A / NPE-240S
199,900 BTU/h Outdoor LP TGH-C95XLP Not Available Not Available NPE-240A / NPE-240S
All variants are ready for U.S. and Canada.
Note: Manifold control ready units can be daisy chained together. If you have the heaters common vented, you can still manifold up to 20 units, you just have to limit the common venting to 10 units maximum. Each manifold control ready unit comes with a cable for connection. (No MIC-6 or MIC-185 required for manifold control ready models; MIC-6 and MIC-185 controllers can still be used with commercial tankless models.) 180k and 157k BTU/h models will remain available as residential models that can be converted for commercial use by purchasing the Commercial Program Chip Accessory.

Why Rheem Commercial?

Building on nearly a century of innovation, the Rheem HVAC Line is the next step in our evolution—commercial HVAC solutions designed to provide perfect comfort, flexibility and support for any business application. All supported by the commercial experts at Rheem.

BIM Support

More accurately design and estimate cost for jobs in less time with compatible spec data, 2D and 3D CAD® files and Revit® files.

EZSpec™ Selection Tool Software

We offer smart selection tools to help you specify, select and document all Rheem equipment for new construction or replacement in all commercial applications.

Customized Solutions

With a breadth of heating and cooling solutions and built–to–order systems to suit your business needs, design and application requirements–there’s no need to overpay for unnecessary “packages.”

Guaranteed Performance

Rheem backs every commercial unit with our industry–leading commercial limited warranty–so your business can count on protected performance year after year.

Faster Lead Time

Our vast distribution network across the US and Canada means improved factory lead times to help avoid business downtime.

Dedicated Technical Support

From our dedicated support team to resources such as MyRheem.com, our Innovative Learning Centres, live product assistance and more, Rheem is here to support you at every step.

com-tankless-img-18
Note: Most residential tankless accessories are not recommended for use with commercial applications; However, some venting accessories used with residential tankless can also be used with individually vented commercial tankless applications.

Parts & Accessories

EZ Rack Kit

  • Mounts one or multiple tankless water heaters for indoor or outdoor applications
  • Compactly packaged for assembly on site
  • Offers free-standing or wall-mounted configuration
  • Expandable by adding tankless rack accessory kits

EcoNet WiFi Kit

  • Enables control and monitoring of single or manifolded water heaters from anywhere*
  • Sends mobile reminders when it’s time for maintenance
  • Shuts off gas and water if a water leak is detected

Common Venting Parts & Accessories

  • Vent up to 10 units with only 1 outer wall penetration
  • Direct Vent & Room Air header kits
  • Back-to-back configurations
  • 6″, 8″ and 10″ trunk lines
  • Polypropylene stabilized (PPs) easily connects with no glues or solvents

Maximum Vent Length (air intake and exhaust) each:

NUMBER OF WATER HEATERS 6″ COMMON VENT 8″ COMMON VENT 10″ COMMON VENT
2 70″ (30cm) 100″ (30 m) 100″ (30 m)
3 50″ (15cm) 100″ (30 m) 100″ (30 m)
4 40″ (15cm) 100″ (30 m) 100″ (30 m)
5 N/A 100″ (30 m) 100″ (30 m)
6 N/A 78″ (24 m) 100″ (30 m)
7 N/A 55″ (17 m) 100″ (30 m)
8 N/A 43″ (13 m) 100″ (30 m)
9 N/A N/A 100″ (30 m)
10 N/A N/A 85″ (26 m)

Top Commercial Tankless Applications

Hotels / Hospitality
  • Often require multiple units and the ability to connect up to 20 units easily is a big benefit
  • Consistent guest service is a top priority; having redundancy in their system provides less downtime

Restaurants / Food Service
  • Need hot water to operate legally and having redundancy in the system limits downtime
  • Need hot water at 185°F for dishwashers and Rheem Commercial units can do this without an upgrade kit

Offices
  • Often require two units and the ability to connect units easily is a big benefit
  • Having redundancy in the system provides peace-of-mind

Schools
  • Installation flexibility allows schools to put units throughout the campus, closer to where the hot water is needed, rather than in a single boiler / mechanical room

Senior Care
  • Precise control of hot water temperature provides added safety

Athletic Facilities/ Gyms
  • Produces hot water only as it’s needed for energy savings when not in use with no standby energy losses

Go Tankless

Deploy an advanced commercial tankless system for your business.
